| Chassis |
6” extended A-Frame,
12” Truss chassis |
6" x 1950mm A-frame, 4+4” chassis &
wheelbox riser (Flat Floor) |
6" x 1950mm A-frame, 4+4” chassis &
wheelbox riser (Flat Floor) |
6" extended A-Frame,
4" chassis, 4" riser |
| Hitch Type |
DO45 by Cruisemaster
recessed & 4.5T chains |
DO35 by Cruisemaster
recessed hitch |
DO35 by Cruisemaster
recessed hitch |
3.5T AL-KO 50mm
ball recessed hitch |
| Suspension |
4.5T Cruisemaster ATX Air Lvl 5
BCS with 12” drum brakes
& Bosch ABS & sway control |
4.5T Cruisemaster
XT Air L3 manual
& 12” drum brakes |
2.8T (S/A) / 3.7T Cruisemaster
XT coil with
12” drum brakes |
3.3T Cruisemaster CRS2 country
road & 10” drum brakes |
| Frame |
Structural grade
ply jigsaw construction
Optional upgrades:
SPR aluminum frame
or CNC composite
jigsaw frame |
Structural grade
ply jigsaw construction
Optional upgrades:
SPR aluminum frame
or CNC composite
jigsaw frame |
Structural grade
ply jigsaw construction
Optional upgrades:
SPR aluminum frame
or CNC composite
jigsaw frame |
Structural grade
ply jigsaw construction
Optional upgrades:
SPR aluminum frame
or CNC composite
jigsaw frame |
Electrical
System |
Victron 24V Off-Grid Touch50, 100/50A
MPPT, 15A DC, 120A/ 5000VA InverterCharger, 1000W-24V
solar, 7.2kWh / 600Ah @12V, integrated
gauges behind fridge installation |
Redarc Alpha 75 management
system, 75A maximum via solar
and-or AC, 400Ah lithium battery
(2x200Ah) 800W solar (4x200W-12V panels), 2600W
inverter under lounge installation |
Redarc Alpha 50 management system,
50A maximum via solar, DC and-or AC
/ no inverter, 200Ah lithium battery
(1x200Ah) 600W solar (3x200W-12V
Panels), LCD gauges under lounge installation |
Redarc Manager 30 management system,
30A maximum via solar,
DC and-or AC / no inverter,
200Ah lithium battery 600W solar (3x200W-12V panels),
LCD gauges under lounge installation |
Water
Capacity |
2 x 70-100L fresh water tanks,
100L grey water tank
& 55L dedicated drinking
water tank |
2 x 70-100L fresh water tanks,
100L grey water tank
& 70L dedicated drinking
water tank |
2x 70-100L
fresh water tanks,
100L grey water tank |
2x 70-100L
freshwater tanks |
Stone
Deflector |
Standard |
Standard |
*Optional upgrade |
*Optional upgrade |
Chassis
Finish |
MIPA coat black or hot dip galvanised |
MIPA coat black or hot dip galvanised |
Painted monument grey chassis |
Painted monument grey chassis |
Anderson
Plug |
1x grey Anderson Plug,
1x yellow portable solar input |
1x grey Anderson Plug,
1x yellow portable solar input |
1x grey Anderson Plug |
1x grey Anderson Plug |
| Media |
Fusion audio & speakers (RA670)
includes AM-FM radio, AUX, USB
& bluetooth & smart phone connectivity 2x
fusion internal speakers fusion
soundpanel external speakers |
Fusion audio & speakers (RA670)
includes AM-FM radio, AUX, USB
& bluetooth & smart phone connectivity 2x
fusion internal speakers fusion
soundpanel external speakers |
Fusion audio & speakers (RA60)
includes AM-FM radio, AUX, USB & bluetooth 2x fusion
internal speakers 2x fusion
external speakers |
Fusion audio & speakers (RA60)
includes AM-FM radio, AUX, USB & bluetooth 2x fusion
internal speakers 2x fusion
external speakers |
Dust
Reduction |
Standard |
Standard |
*Optional upgrade |
*Optional upgrade |
Recovery
Points & Skid
Plates |
Standard |
Standard |
*Not applicable |
*Not applicable |
| Storage Boxes |
One-Piece (TB98) storage box
with hinged lid in centre,
gas cylinder centre rebate
(2 slides & 12v socket) |
Dual (TB10) tunnel boxes
with 2 slide-out trays (700L x 370W)
side hinged door & 12v socket
790L x 600H x 500W |
Tunnel box (E40) with
2 slide-out trays & 12v socket, side hinged door
1400L x 600H x 460W |
Tunnel box (E40) with
2 slide-out trays & 12v socket, side hinged door
1400L x 600H x 460W |
| Interior |
Splashback: Perspex,
pressed tin, matching
bnenchtop laminate
cupboard drawers:
soft close drawers |
Splashback: Perspex cupboard drawers: metal-sided |
Splashback: Perspex cupboard drawers: metal-sided |
Splashback: Perspex cupboard drawers: metal-sided |
| Heater |
Hydronic diesel heater |
*Optional upgrade |
*Optional upgrade |
*Optional upgrade |
Safety
Inclusions |
Everything included on Adventus,
Amaroo & Hornet
AND Bosch
& Sway Control |
Breakaway, smoke & carbon monoxide detector,
LPG detector, fire blanket & fire extinguisher |
Breakaway, smoke & carbon monoxide detector,
LPG detector, fire blanket & fire extinguisher |
Breakaway, smoke & carbon monoxide detector,
LPG detector, fire blanket & fire extinguisher |
Wheels
& Tyres |
Grid black 16”
265/75R16 BF Goodrich tyres
K02 6x 139 ETO,
or, ROH Hammar 16” 265/75R16
Falken AT3W 6x139 ET0 |
Grid 16" 265/75R16
All-Terrain 6x 139 ET0 |
Grid 16" 265/75R16
All-Terrain 6x 139 ET0 |
Devil 15" 235/75R15
All-Terrain 6x 139
ET0 |
Outdoor
Shower |
Standard |
Standard |
Standard |
*Optional upgrade |
Mood
Lighting |
Amber mood lighting |
Amber mood lighting |
Amber mood lighting |
*Optional upgrade |
| Step |
Double aluminium step |
Double aluminium step |
Double aluminium step |
Single aluminium
step |
